Product Information / Technical Specifications

Printer

General
Environmental
Mechanical
Electrical
Safety and approvals
PostScript

General

Printing method:

Laser beam scanning and dry electrophotographic process

Resolution:

600 dpi, 300dpi

Continuous printing speed:

A4:

35 pages per minute or less

Letter:

34.5 pages per minute or less

First print (with A4/Letter):

Less than 10 seconds from the MP tray

Less than 10 seconds from the standard cassette

Warm-up time:

About 70 seconds or less at normal temperature

Paper feed:

Automatic or manual feed

Paper feed alignment:

Center alignment for all sizes

Input paper supply:

MP tray:

Up to 200 sheets of plain paper (20 lb)

Up to 20 sheets of envelopes, labels, thick paper, and transparencies

Standard cassette:

Up to 500 sheets of plain paper (20 lb)

Paper output capacity:

Up to 500 sheets (larger than B5/EXE)

Internal emulation:

HP listed LaserJet 4 emulation (LJ4 mode)

HP-GL/2 emulation (GL2 mode)

ESC/P2 24-pin printer emulation
(ESCP2 mode)

ESC/P 9-pin printer emulation (FX mode)

IBM Proprinter emulation (I239X mode)

Resident fonts:

84 scalable fonts, and 7 bitmap fonts

RAM:

32 MB, expandable up to 544 MB


[Top]

Environmental

Temperature:

In use:

10 to 35°C (50 to 95°F)

Not in use:

0 to 35°C (32 to 95°F)

Humidity:

In use:

15 to 85% RH

Not in use:

10 to 85% RH

Altitude:

2,500 meters (7,263 feet) or less


[Top]

Mechanical

Dimensions
and weight:

Height:

42.2 cm (16.6 in.)

Width:

53.9 cm (21.2 in.)

Depth:

56.6 cm (22.3 in.)

Weight:

Approx. 28 kg (61.7 lb) without consumable installed

Durability:

Printing Volume:
Maximum 100,000 sheets/month
Average 15,000 sheets/month


[Top]

Electrical

110 V to 120 V Model
(Model L390A)

220 to 240 V Model
(Model L390A)

Voltage

110 V-120 V ± 10%

220 V-240 V ± 10%

Rated frequency

50 Hz / 60 Hz ± 3 Hz

50 Hz / 60 Hz ± 3 Hz

Rated current

9.5 A

5.5 A

Power consumption

During printing*

Maximum

1100 W

1100 W

Average

700 Wh

715 Wh

During standby mode

Average

165 Wh

175 Wh

Sleep mode

21 Wh

20 Wh

*  Includes optional paper cassette unit.


[Top]

Safety and approvals

U.S. model:

Safety

UL 60950
CSA No.60950

EMC

FCC Part 15 Subpart B Class B
CSA C108.8 Class B

European model:

Low Voltage Directive 73/23/EEC
EMC Directive 89/336/EEC

EN 60950
EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3

Australian model:

EMC

AS/NZS 3548 Class B

Laser safety

This printer is certified as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS) Radiation Performance Standard according to the Radiation Control for Health and Safety Act of 1968. This means that the printer does not produce hazardous laser radiation.

Since radiation emitted by the laser is completely confined within protective housings and external covers, the laser beam cannot escape from the machine during any phase of user operation.

CDRH regulations

The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. Compliance is mandatory for products marketed in the United States. The label shown below indicates compliance with the CDRH regulations and must be attached to laser products marketed in the United States.


[Top]

PostScript

Language

Adobe PostScript 3

Emulation name

in PJL: POSTSCRIPT
in EJL: PS

AppleTalk protocol

Entity Type: LaserWriter
Emulation Type: POSTSCRIPT-00


[Top]


Previous

Next
Version NPD0173-00, Copyright © 2003, SEIKO EPSON CORPORATION
