Product Information / Technical Specifications

Printer

General
Environmental
Safety approvals
Mechanical
Electrical

General

Printing method:

Laser beam scanning and dry electrophotographic process

Resolution:

600 dpi

Printing speed:

Up to 16 pages per minute with A4 paper, depending on the font and data quantity

First print:

Less than 15 seconds with A4 paper/Letter paper

(When feeding from MP tray at 600 dpi)

Paper feed:

Automatic feed

Paper feed alignment:

Center alignment for all sizes

Input paper supply
(75 g/m2 paper):

Up to 150 sheets of plain paper
Up to 10 envelopes, depending on thickness

Paper output:

Face-down or Face-up (optional) selection

Paper output capacity
(75 g/m2 paper):

Up to 100 sheets of plain paper (face-down)

Up to 20 sheets of plain paper (face-up, optional)

RAM:

2 MB


[Top]

Environmental

Temperature:

In use:
Not in use:

10 to 35°C (50 to 95°F)
0 to 35°C (32 to 95°F)

Humidity:

In use:
Not in use:

15 to 85% RH
10 to 85% RH

Altitude:

2,500 meters (8,200 feet) maximum


[Top]

Safety approvals

Safety standards:

U.S. model:

UL 60950
CSA C22.2 No.60950

European model:

Directive 73/23/EEC

EN60950

EMC:

U.S. model:

FCC part 15 subpart B class B
CSA C108.8 Class B

European model:

Directive 89/336 /EEC

EN 55022 (CISPR Pub. 22) class B

EN 55024

EN 61000-3-2

EN 61000-3-3

Australian model:

AS/NZS 3548 class B

CDRH regulations

The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. Compliance is mandatory for products marketed in the United States. The label shown below indicates compliance with the CDRH regulations and must be attached to laser products marketed in the United States.


[Top]

Mechanical

Dimensions and weight:

Height:

256 mm

Width:

399 mm

Depth:

263 mm

Weight:

Approx. 7 kg,
excluding the developer cartridge and photoconductor unit

Durability:

5 years or 180,000 sheets, whichever comes first


[Top]

Electrical

Model

110 V to 120 V model

220 to 240 V model

Voltage

110 V - 10%, 120 V + 10%

220 V - 240 V ± 10%

Rated frequency

50 Hz ± 3 Hz / 60 Hz ± 3 Hz

Rated current

7.2 A

3.8 A

Power consumption

Less than 710 W

Less than 720 W

Power consumption
in sleep mode

Less than 7 W (When heater is off)

Less than 8 W (When heater is off)

Note:
Check the label on the back of the printer for the voltage of your printer.


[Top]


Previous

Next
Version 1.00E, Copyright © 2002, SEIKO EPSON CORPORATION
