Product Information / Technical Specifications

Printer

General
Environmental
Safety approvals
Mechanical
Electrical

General

Printing method:	Laser beam scanning and dry electrophotographic process
Resolution:	600 x 600 dpi, 300 x 300 dpi,
Continuous printing speed (with A4/Letter):
Color printing:	5 pages per minute or more
Black only printing:	20 pages per minute or more
First print (with A4/Letter):
Color printing:	Less than 25 seconds
Black only printing:	Less than 16 seconds
Warm-up time:	About 160 seconds (220V) or 150 seconds (120V) at normal temperature
Paper feed:	Automatic feed
Paper feed alignment:	Center alignment for all sizes
Input paper supply:
MP tray:	Up to 150 sheets of plain paper, EPSON Color Laser Paper Up to 10 envelopes Up to 50 sheets of labels, thick paper, or transparencies
Standard lower cassette:	Up to 500 sheets of plain paper, EPSON Color Laser Paper
Optional 500-Sheet Paper Cassette Unit:	Up to 500 sheets of plain paper, EPSON Color Laser Paper
Paper output:	For all paper types
Paper output capacity:	Up to 500 sheets of plain paper, EPSON Color Laser Paper
RAM:	16 MB, expandable up to 256 MB (you need to remove the standard 16 MB module and install two 128 MB modules to expand your printer memory to 256 MB)

[Top]

Environmental

Temperature:
Operation:	10 to 32 °C (50 to 90 °F)
Storage:	0 to 35 °C (32 to 95 °F)
Humidity:
Operation:	15 to 85% RH
Storage:	30 to 85% RH
Altitude:	2,500 meters (8,200 feet) maximum

[Top]

Safety approvals

Safety standards:

U.S. model:

UL 1950
CSA C22.2 No.950

European model:

Directive 73/23/EEC

EN60950

EMC:

U.S. model:	FCC part 15 subpart B class B
European model:	Directive 89/336 /EEC
	EN 55022 (CISPR Pub. 22) class B EN 55024 EN 61000-3-2 EN 61000-3-3
Australian model:	AS/NZS 3548 class B

Laser safety

This printer is certified as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS) Radiation Performance Standard according to the Radiation Control for Health and Safety Act of 1968. This means that the printer does not produce hazardous laser radiation.

Since radiation emitted by the laser is completely confined within protective housings and external covers, the laser beam cannot escape from the machine during any phase of user operation.

CDRH regulations

The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2, 1976. Compliance is mandatory for products marketed in the United States. The label shown below indicates compliance with the CDRH regulations and must be attached to laser products marketed in the United States.

[Top]

Mechanical

Dimensions and weight:
Height:	511 mm (20.1 in.)
Width:	463 mm (18.2 in.)*
	*When extending all trays, 620 mm (24.4 in.)
Depth:	559 mm (22 in.)
Weight:	Approx. 45 kg (about 99.2 lb) excluding options Approx. 39.5 kg (about 86 lb) excluding options and consumables
Durability:	5 years or 500,000 sheets, whichever comes first

[Top]

Electrical

	110 V/120 V Model	220 to 240 V Model
Voltage	120 V ± 10%	220 V/240 V ± 10%
Rated frequency	50 Hz ± 3 Hz /60 Hz ± 3 Hz	50 Hz ± 3 Hz /60 Hz ± 3 Hz
Rated current	Less than 10 A	Less than 6 A
Power consumption	Less than 1,000 W	Less than 1,100 W
Power consumption in standby mode	Less than 30 W	Less than 30 W
